This solution is based on the principles of eddy current detection and electromagnetic induction. It uses metal classification and identification detection technology, as well as magnetic field transformation technology, to obtain the material and shape information of metal objects, thereby achieving the separation of metal contraband from daily metal items. The system mainly consists of a detection gate, excitation signal transmission module, eddy current/electromagnetic signal sensor, signal processing and control module, data processing module, and remote monitoring system.
The detection modes are divided into mobile phone detection mode, contraband detection mode, all-metal mode, and electronics+contraband mode.
When passing through the security check gate, metal buttons, necklaces, lighters, keys, coins, belt buckles, compasses, hairpins, thermos cups, folding umbrellas and other metals on normal clothing will not trigger an alarm. When carrying electronic products, the system will give an audible and visual alarm, prompt in the form of graphics and text, and indicate the hiding position. The detection and alarm are not affected when the mobile phone is in standby, shutdown, battery-removed, SIM card-removed, or wrapped in five layers of copper foil and tin foil.
When passing through the security check gate, small metals that do not exceed the alarm threshold, such as metal buttons, necklaces, lighters, keys, coins, belt buckles, compasses, hairpins on normal clothing, and electronic products such as mobile phones, will not trigger an alarm. An alarm will be issued when carrying contraband such as knives, guns, wrenches, and hammers.
When personnel pass through the security check gate in a standard posture, small metals exceeding the alarm threshold, such as coins, keys, metal buttons, belt buckles on normal clothing, and contraband, will trigger an alarm and prompt the hiding position of the contraband.
The mobile phone+contraband mode combines the advantages of the mobile phone detection mode and the contraband detection mode to ensure that the security check gate can effectively detect and alarm in different situations. Metals such as metal buttons, necklaces, lighters, keys, coins, belt buckles, compasses, hairpins on normal clothing, and electronic products such as mobile phones will not trigger an alarm, ensuring the convenient passage of general clothing and daily carry-on items. At the same time, when carrying electronic products or hidden contraband such as knives, guns, wrenches, hammers, etc., the system will immediately give an audible and visual alarm, prompt in the form of graphics and text, and even indicate the hiding position, so as to effectively prevent the carrying and use of contraband. This mode can flexibly respond to safety detection needs in different situations and ensure the efficient use of safety equipment.
Support alarm record export and statistics of the number of people in and out. Customizable header text and (signature text). Zone sensitivity, frequency setting, item selection setting.
The security check gate can communicate with the server through a 4G network to realize remote parameter setting and passage record upload. It communicates with the server stably through the TCP protocol to realize remote parameter setting, such as sensitivity, alarm threshold, detection mode, etc. At the same time, the security check gate can upload passage records to the server through the 4G network, including detailed information such as the number of people passing through the security check gate and alarm conditions.
It is specially designed to detect carried electronic devices. Its main functions include detecting electronic devices such as Bluetooth headsets and smart glasses. When passing through, the system will give an audible and visual alarm and prompt in the form of graphics and text to ensure the comprehensiveness and accuracy of safety inspection.
Through the convenient operation of the web page of the cloud platform, users can remotely set the parameters of the security check gate, including setting the detection mode, alarm items, and zone sensitivity. At the same time, users can easily query detection records through the web interface, including detailed information such as the number of people passing through the security check gate and alarm conditions for data analysis and monitoring.
Applicable Industries
1. It is applicable to exam halls and schools for managing students' mobile phones.
2. It is applicable to prisons to prevent the carrying of communication tools such as mobile phones.
3. It is applicable to confidential places in the military, such as confidential meeting rooms, intelligence offices, and operation rooms.
4. It is applicable to locations where mobile phones are prohibited and electromagnetic waves need to be shielded, such as nuclear power plants and oil depots.
5. It is applicable to work units with strict requirements for mobile phone calls, such as government agencies, courts, airports, and large - enterprise meeting rooms.
It is applicable to any other place where mobile communication is restricted.
Parameters
Model: 9000 (Supports network connection, cloud platform, and connection to gate machines)
Display Screen: 29 - inch front and rear dual - screen
Mouse: Wireless mouse
System: Win10
Detection Zones: 8 - zone
Interfaces: Supports RJ45, RS232, RS485, SD card, USB, I2C, SPI
Frequencies: 12
Sensitivity: Sensitivity can be adjusted in 256 levels.
Resistance to Stationary Metal Influence: Unaffected by large stationary metal objects outside a 60 - cm range around the door body.
Resistance to Ground - Internal Metal Structure Influence: Unaffected by metal structures 0.1 m below the ground.
Magnetic Induction Intensity: <11uT
Alarm: The light strip lights up to remind, the LCD screen graphically indicates the location and suspected item, and the sound reminder is >90dB.
Test Data Storage: >10000 records
Counting Function: Records the number of inspected and alarmed people.
Camera: Dahua 2 - megapixel. Storage Capacity: 128G, which can store 100,000 captured pictures.
Input Power: 187V - 242V, 50/60Hz
Total Machine Weight: Approximately 150 kg
Total Machine Power Consumption: 150W
Working Environment: -20℃ - 60℃
Alarm Sound: >90dB
Overall Dimensions (mm): 2420*900*700
Passageway Dimensions (mm): 1980*710*650
Pass - through Speed: <1 second
Detection Efficiency: ≥40 people per minute
Optional camera with hard - disk storage.
All parameters comply with the national standard GB15210 - 2018
*General Technical Specifications for Walk - through Metal Detection Gates*.
